TS-AD1 Antenna System

UHF wide frequency band(450~950MHz)design enable 4 sets of receiver to share the antenna
Built-in power distribution system supplies power for 4 receivers
Built-in power supply circuit in the antenna input interface supplies power for the antenna amplifier directly
Independant protection circuit for each power port assures the normal operation of the other units when one of the receiver has a breakdown
The main power switch controls the power supply of all devices

Sản phẩm chi tiết

Ứng dụng
Đặc điểm kỹ thuật
Product Tutorial

Engineering application, outdoor performance

• Frequency Range: 450～950MHz
• Antenna Interface: TNC/50Ω
• Max. Output Power: -3 dBm
• Total Gain: > 3 dB
• Output Port Seperation: > 15 dB
• Antenna Input Port Power: DC 8V/100mA
• Power Input Voltage: 12V/3000mA
